TL;DR
China has begun mass-producing some advanced chip manufacturing tools domestically, signaling progress. However, the critical ‘learning-by-doing’ barrier—gaining reliable, high-yield production—remains a significant challenge. This development impacts China’s long-term AI chip capabilities.
China has begun mass-producing domestic immersion deep ultraviolet (DUV) lithography machines capable of manufacturing chips at 28 nanometers and potentially at 7- and 5-nanometer nodes, according to credible sources. This development impacts China’s long-term AI chip capabilities. This marks a significant step in China’s efforts to develop its semiconductor industry amid export restrictions, but the ability to produce these chips reliably at scale remains an unresolved challenge.
Multiple credible reports indicate that China has started mass production of domestic immersion DUV lithography machines, which are essential for advanced chip manufacturing after export controls limited access to EUV technology. These systems are tied to firms linked to Huawei and are evaluated at SMIC, China’s leading foundry. These systems are tied to firms linked to Huawei and are evaluated at SMIC, China’s leading foundry. The machines target 28-nanometer production, with the capability to reach 7-nanometer and possibly 5-nanometer nodes through multi-patterning techniques.
Separately, Reuters has reported the existence of a domestic EUV prototype, though it remains in early development stages. For more on China’s advancements in AI and space technology, see this insight. SMIC has demonstrated 7-nanometer production using older DUV tools, and is reportedly working toward 5-nanometer capabilities. Huawei aims to produce over a million high-end AI-accelerator chips this year. Despite these advances, the core challenge is not just the existence of machines but achieving reliable, high-yield, commercial-scale production, which is a much more complex hurdle.
Every few weeks a headline says China cracked the last hard problem in chipmaking — and triggers alarm in one camp, triumph in the other. Both overreact, because both mistake a learning-by-doing problem for a copying problem. It isn’t one.
▲ Forward-looking · figures are point-in-time estimates“A machine exists” and “a machine makes advanced chips at scale, profitably, for years” are separated by a chasm — made of things that only accumulate with time.
In a race, a burst of speed closes the gap. In a phase transition, you can’t move faster to cross over — you have to accumulate enough, slowly, until the system changes state.
When you see “China achieves X,” ask which of two very different claims is actually being made.
Even amid the loud headlines, the quiet data points all say the same thing.
No prototype, no shipped tool, no yield headline teleports past it.
Implications of the 'Learning-by-Doing' Barrier for China’s Tech Ambitions
This progress signifies that China is moving up the technology stack in chip manufacturing, backed by significant state support. However, the learning-by-doing barrier—accumulating the tacit knowledge to produce chips reliably at high yields—remains a formidable obstacle. Overcoming this is essential for China to produce advanced chips at scale, which directly impacts its ambitions in AI and high-tech industries. The gap between prototype capability and commercial reliability means China’s progress, while notable, is still in early stages and will take years to fully realize.
The MACHINE that makes the MACHINES: Inside ASML and the race to control the future of microchips (AI)
As an affiliate, we earn on qualifying purchases.
As an affiliate, we earn on qualifying purchases.
Challenges in Transitioning from Prototype to Reliable Production
While China has made notable strides in developing domestic lithography tools, the industry still faces significant hurdles. Yields for 5-nanometer chips are estimated at around 20%, compared to 90% in leading Western fabs using EUV technology. Achieving high yields requires extensive tacit knowledge—gained through years of running large-scale production, fixing failures, and refining processes—which China is still developing. Additionally, China remains dependent on imported high-purity materials, such as photoresist from Japan, and its tools lag behind leading-edge technology by several generations.
Furthermore, China’s installed base of DUV tools relies heavily on Western servicing and maintenance, creating a dependency that slows progress toward fully self-sufficient high-end manufacturing. Independent forecasts suggest that domestically-made tools will not reach sub-10-nanometer production at commercial scales before around 2030, emphasizing the long timeline ahead.
"The real challenge isn’t just building the machines, but accumulating the tacit knowledge needed to produce chips reliably at high yields."
— Thorsten Meyer
domestic immersion DUV lithography system
As an affiliate, we earn on qualifying purchases.
As an affiliate, we earn on qualifying purchases.
Unresolved Challenges in Achieving High-Yield, Commercial-Scale Production
It remains unclear how quickly China can improve yields from the current 20% level to the 90% standard seen in leading fabs. The timeline for domestically-produced tools to reach sub-10-nanometer commercial production is uncertain, with estimates ranging into the next decade. Additionally, whether China can fully overcome dependencies on imported materials and servicing remains an open question.
28 nanometer semiconductor fabrication equipment
As an affiliate, we earn on qualifying purchases.
As an affiliate, we earn on qualifying purchases.
Next Steps in China's Semiconductor Development Timeline
China will continue to scale its domestic lithography production, aiming to improve yields and reduce dependencies. The focus will be on process refinement, material sourcing, and building a self-sufficient supply chain. Monitoring SMIC and Huawei’s production milestones over the next 1-3 years will be key indicators of progress. Additionally, breakthroughs in materials or process innovations could accelerate China’s capabilities, though significant challenges remain before achieving fully reliable, high-volume production at sub-10-nanometer nodes.
high-yield AI chip production tools
As an affiliate, we earn on qualifying purchases.
As an affiliate, we earn on qualifying purchases.
Key Questions
What is the 'learning-by-doing' wall in chip manufacturing?
The 'learning-by-doing' wall refers to the challenge of gaining the tacit knowledge needed to produce chips reliably at high yields, which can only be acquired through extensive, scaled manufacturing experience over time. It is a barrier that cannot be overcome simply by building machines or acquiring technology.
Why is yield so important in chip manufacturing?
Yield measures how many chips produced are functional. High yields mean cost-effective, reliable production at scale. Low yields, like the current 20%, mean many chips are discarded, making manufacturing unprofitable and limiting capacity.
How does material dependency affect China’s chip ambitions?
China relies heavily on imported high-purity materials, such as photoresist from Japan, which are essential for advanced manufacturing. This dependency hampers full self-sufficiency and slows progress toward high-volume, high-quality production.
When might China achieve sub-10 nanometer commercial production?
Most credible forecasts suggest this could happen around 2030, but the timeline depends on overcoming yield, material, and technological gaps.
